Our hydroponic glass greenhouse is a premium Venlo-type multi-span automated facility, tailor-made for commercial agricultural enterprises and large-scale soilless cultivation operators. This high-efficiency soilless cultivation greenhouse adopts a heavy-duty hot-dip galvanized steel frame and high-transmission tempered glass, integrating intelligent fertigation, vertical growing systems and precision climate regulation. It creates a sterile, high-yield growing space for leafy greens, herbs and seedlings, drastically cutting water, fertilizer and labor input while elevating unit-area output to meet the mass production demands of modern commercial hydroponic growing facilities.
4mm/5mm anti-drip float glass delivers over 90% light transmittance, ensuring even natural light distribution for stable and healthy crop growth without dead zones.
Q235/Q345 hot-dip galvanized steel skeleton resists wind load ≥ 0.55kN/m² and snow load ≥ 0.45kN/m², with a frame service life of over 15 years for long-term stable operation.
Integrated intelligent fertigation and vertical pipeline irrigation support remote monitoring, realizing low-labor and high-precision nutrient supply for soilless crops.
Modular multi-span and vertical cultivation design increases land yield by over 30% compared with traditional soil-based planting greenhouses.
Soilless cultivation technology completely avoids soil-borne diseases, reduces pesticide use and guarantees the food safety of commercial vegetable products.
Parameter Item | Standard Data |
Frame Structure | Venlo Type Multi-span Hot-dip Galvanized Steel Glass Greenhouse |
Frame Material | Q235/Q345 Hot-dip Galvanized Steel |
Covering Material | 4mm/5mm Tempered Float Glass (UV-resistant, anti-drip) |
Standard Span | 9.6m / 10.8m / 12m (fully customizable) |
Bay Spacing | 4m / 8m (fully customizable) |
Column Height | 3m / 4m / 6m (fully customizable) |
Ridge Height | 4.5m / 6m / 7.5m (fully customizable) |
Wind Load Resistance | ≥ 0.55kN/m² |
Snow Load Resistance | ≥ 0.45kN/m² |
Light Transmittance | 90%+ |
Frame Service Life | 15+ Years |
Glass Service Life | 20+ Years |
HS Code | 9406900090 |
This commercial soilless glass greenhouse is ideal for large-scale hydroponic vegetable factories producing lettuce, herbs and leafy greens. It also fits vertical hydroponic planting bases for high-density crop cultivation, agricultural tech demonstration parks for science popularization, off-season vegetable production bases for domestic and export markets, and soilless seedling breeding centers for ornamental plants.
Conduct pre-operation inspection to check steel frame tightness, glass sealing, hydroponic pipelines and electrical circuits on a daily basis. Adjust temperature, humidity and ventilation parameters via the intelligent control cabinet to realize automatic environmental regulation for crop growth. Program the fertigation system to supply precise nutrient solution based on different crop growth stages, and monitor EC/pH values of the solution consistently. Clean glass surfaces regularly to maintain high light transmittance, and inspect irrigation nozzles and hydroponic pipelines to remove blockages in a timely manner. Perform monthly maintenance on power systems and complete a full structural inspection on an annual basis to ensure stable operation.
It is fully compatible with NFT, vertical pipeline, DWC and substrate hydroponic systems, perfectly matching commercial soilless cultivation needs of professional planting practitioners.
All dimensions and configurations are 100% customizable to fit crop types, local climates and production scales of horticultural businesses.
We provide full turnkey solutions including design, manufacturing, installation, global shipping and professional after-sales technical guidance for all cooperative clients.
